▌ SETTING THE TRACKER CC MAPPING
1. Connect Play+ as the primary lead and Tracker as the secondary
follower using the MIDI Jack adapters or via a USB Hub.
2. The default MIDI Control parameters are assigned to Knobs for CC#’s
12, 13, 17, 19, 22, 71, 74 and 75. These can be changed in batch for
Tracker integration.
3. Press (Screen) to open the main conguration menu. Turn the (Screen)
knob to navigate to highlight ‘MIDI’. Press (Screen) to open the MIDI
sub-menu. If the menu is not at the main menu, press [Back] to backup.
4. Turn the (Screen) knob to navigate to highlight ‘CC Mapping’. Press
(Screen) to open the CC Mapping sub-menu.
5. Turn the (Screen) knob to navigate to highlight the MIDI output port and
channel which connects the Tracker. The Jack refers to the MIDI out
connected with the 5-Pin DIN Adaptor and USB refers to the same
connection as power. Press (Screen) to open the Port /Channel
mapping page.
6. The 8 CC Parameter congurations and an option for Polyend Tracker
is also listed. Turn (Screen) to highlight ‘Set value for Polyend Tracker’
7. Press (Screen) to select and automatically congure the CC#’s to match
the Play+ knobs with the Tracker functions. Play+ will lead and Tracker
follow the CC values.
Play+ Knob MIDI Mode Tracker Destination
Filter Cutoff CC 1 Filter Cutoff
Resonance CC 11 Resonance
Sample Attack CC 104 Wavetable Position - LFO Speed
Sample Decay CC 107 Wavetable Position - LFO Amount
Reverb Send CC 14 Reverb Send
Delay Send CC 15 Delay Send
Overdrive CC 12 Overdrive
Bit Depth CC 13 Bit Depth
Trackers MIDI settings will also need to be congured to receive MIDI
messages and clock from Play+.
