Potter PFC-6006 - Uploading from Panel to Computer

5-27
PFC-6006 • 5403559 • REV D • 11/17
Uploading from Panel to Computer
The Upload Conguration File to Computer transfer icon is used to upload the conguration le from the panel to the
computer once the LEARN function is completed or whenever points are added or removed from the panel.
To upload programming changes to computer:
1. Click the Upload Conguration File to Computer icon or right click from “Transfers” region as shown below:
Figure 20. Example of Transfer Shortcut Menu
Note: Click the "Add" option from the shortcut menu to choose the transfer type.
The Transfer dialog box displays.
Figure 21. Example of Transfer Upload Dialog Box
2. Verify that Upload is selected in the “Transfer Type” eld.
3. Enter the conguration lename in the “Filename” eld or leave blank to Autoname.
Figure 22. Example of Transfer – Upload Window
Notes:
•y If you do not name the le, the program automatically names it using the transfer type and date stamp as the
le name.
•y Once the le has been saved, and additional programming changes are made at a later date, click the Browse button to
locate the le name to replace the old le with the updated conguration changes.
Click here to choose applicable
transfer type, if necessary.
Enterlenameorleaveblank
to auto-name.
Right click anywhere in the
transfer window to display
the shortcut menu.
