2-2
PFC-6006 • 5403559 • REV D • 11/17
Section 2: Before You Start Installation
This section addresses information that will help you in completing a successful installation, such as the PFC-6006 cabinet layout,
specications, and environmental considerations.
System Specications
Cabinet Description
y Eighteen (18) gauge sheet steel with hinged, removable locked door
y Enclosure dimensions – 18-1/2" x 14-1/4" x 4-3/4"
Visual Indicators
y LCD (2 x 16 alphanumeric character display)
y LED indicators (Red, Green, Amber)
LCD Description
y Alarm, Supervisory and Trouble conditions display applicable condition, status and circuit for each correlating condition
Environmental Specications
y Mount indoors only.
y Temperature 32° to 120°F, humidity 93% non-condensing.
y Verify panel is properly grounded.
y Remove all electronic assemblies prior to any drilling, ling, reaming, or punching of the enclosure. When possible, make
all cable entries from the sides, bottom, or rear of the cabinet. Verify that they will not interfere with the batteries or other
components.
y The panel and system must be tested and maintained in accordance with all local and national codes and ordinances.
y Panel shall be installed so the display is easily readable and the door shall have adequate clearance to access the controls.
Model / Available Cabinet Colors
y 3992334 – RED PFC-6006 Sprinkler Monitoring Panel
y 3992336 – BLACK PFC-6006 Sprinkler Monitoring Panel
System Congurations / Appliances
Table 2: System Congurations / Appliances
Model Description Local
Remote
Station
Central
Station
Proprietary
PFC-6006 Main Board/Panel Assembly Y Y Y Y
RA-6006 LCD remote annunciator (cUL) O O O O
RA-6075 LCD remote annunciator (NFPA) O O O O
3005013 End of line resistor assembly Y Y Y Y
Y = Yes, required for applicable section
N = No, not required for applicable section
O = Optional, may or may not be used, has no affect on the applicable section.
