Potter PFC-6006 - NAC Functions; AUX Functions

5-52
PFC-6006 • 5403559 • REV D • 11/17
NAC Functions
The on-board NAC circuit (NAC 1) is automatically congured as “Conv NAC General Purpose”, but may be recongured to
other functions, as described in the table below:
Table 21: NAC Circuit Conguration Functions
Function Description
General Purpose
General purpose NAC; obeys zone “output pattern” programming, and is
the default.
Potter Sync Drives Potter synchronized horns / strobes.
Gentex Sync Drives Gentex synchronized horns / strobes.
System Sensor Sync Drives System Sensor synchronized horns / strobes.
Wheelock Sync Drives Wheelock synchronized horns / strobes.
AUX Functions
The on-board AUX circuit automatically is congured as “Conv NAC Aux Constant”. Other conguration options are available,
as described in the table below:
Table 22: AUX Circuit Conguration Functions
Function Description
Conv NAC Aux Constant Constant DC power; this is the default.
Conv NAC Aux Resettable Constant DC power; disconnects power during system reset.
Conv NAC Aux Door Holder Constant DC power; disconnects when an alarm occurs.
Conv NAC Aux Door Holder
Low AC Drop
Constant DC power; disconnects on AC Loss or when an alarm occurs.
