MAX™ Operator Manual
©
Original Printed In English
SECTION 2 - SETUP & ADJUSTMENTS
LOADING BAG FILM - BOX POWER UNWIND
2-5
Roller and Drive Roller.
8. Disengage the Dancer Lock from the Dancer Arm.
9. Slowly pull on the web until you have enough
slack to reach the front of the bagger. Figure 2-
5A. As you pull on the web, the Power Unwind will
advance web from the fan fold box. The harder
the web is pulled the faster the web will be ad-
vanced.
10. Push the Jog Button and slowly feed the web into
the Drive Roller until the bagger stops advancing
the film, making sure the web is centered.
Figure 2-5A. Web centered on Drive Roller.
Jog Button
Figure 2-5A. Web Advancement
