Pre Installation Tasks
Tools Required for the Installation
3-2 Preproofer x700 / x900 – HW Installation Manual
PP x700/x900 v1.7
3 Pre Installation Tasks
3.1 Tools Required for the Installation
 Standard screw driver set
 Allen key set
 Phillips screw driver set
 Measurement tape
 Cordless drill to unpack the boxes
3.2 PC Specification
 CPU Intel Core 2 Quad, 2.x GHz (high performance CPU is recommended
 min. 2 GB RAM
 min. 1x 250 GB hard disk drive, 7200rpm
 1x 64 GB Solid State Drive
 min. 4x USB ports
 2x Ethernet ports
 19” TFT monitor (touch screen is recommended)
 Windows XP or Windows 7, 32 bit version
The PC needs to be equipped with a SSD
Drive (min 64GB). The SSD drive is used
because it’s astonishing write performance
on small files as DI-Pilot does it when
communicating between the two Epson
printers, electronic box and the cameras
system.
3.3 Materials Required for Installation
For the setup, prepare the following cables / hubs which are not part of the shipment:
 4x RJ45 Ethernet Cable. Length: 2m, 2m, 3m, 5m
 1x Ethernet Switch 10/100/100 min. 4 Ports
