9 Paper Guide / Camera System
9.1 Side parts - Step 1
9.1.1 Parts used
Pos
Amount
Name
Dimension in mm
03
1
Left sided holder
04
1
Right sided holder
56
2
Bracket
25 x 35
57
5
Screw M5 x 16
