Frame Setup

Overview

4

Preproofer x700 / x900 – HW Installation Manual 4-1

PP x700/x900 v1.7

4 Frame Setup

4.1 Overview

Pos 2 - 795mm

Pos 1 - 2060mm

Pos 5 - 810mm

Pos 3 - 1100mm

Pos 6 - 1980mm

Pos 4 - 650mm

Pos 8 - 305mm
