Preproofer 770 - Mount the Cable Channel; Additional Parts

Assembly
Mount the Cable Channel
5
Preproofer x700 / x900 – HW Installation Manual 5-21
PP x700/x900 v1.7
5.6 Mount the Cable Channel
5.6.1 Additional Parts
Pos
Amount
Name
Dimension in mm
30
1
Cable channel
Fixes the printers to the frame
120 x 80 x 600
31
2
End cover, black
120 x 80
32
8
Pan head tapping screw
4,2 x 9,5
53
2
M5 x 12
2
Slot nut M5
