Preproofer 770 - Add Paper Guide and Paper Tension Parts; Additional Parts

9
Paper Guide / Camera System
Add Paper Guide and Paper Tension Parts
9-14 Preproofer x700 / x900 – HW Installation Manual
PP x700/x900 v1.7
9.9 Add Paper Guide and Paper Tension Parts
9.9.1 Additional Parts
Pos
Amount
Name
Dimension in mm
67
2
Screw M5 x 40
68
2
Screw M5 x 12
69
2
Screw M5 x 20
70
2
Aluminum Tube 20mm
20mm diameter x
30mm length
71
2
Tension Tube Guide
20mm width,
600mm length
01
1
Tube holder, right side
02
1
Tube holder, left side
72
1
Aluminum Tube 20mm
20mm diameter x
1950 mm length
