Preproofer 770 - Page 77

Paper Guide / Camera System
Add Slot Nuts to Profile Front Printer
9
Preproofer x700 / x900 – HW Installation Manual 9-13
PP x700/x900 v1.7
9.8.2 Slot nuts for Paper Guide Profile
Mount four M5 slot nuts into the profile where the
Front printer stands on, each 45 mm from the side
frame.
45 mm
45 mm
