Preproofer 770 - Assembly Right Holder and Camera Holder; Parts Used; Assembly

Paper Guide / Camera System
Assembly „Right Holder“ and „Camera holder“
9
Preproofer x700 / x900 – HW Installation Manual 9-5
PP x700/x900 v1.7
9.3 Assembly „Right Holder“ and „Camera holder“
9.3.1 Parts used
Pos
Amount
Name
Dimension in mm
59
1
Screw M5 x 20
9.3.2 Assembly
Assembly now the two parts like shown.
