Preproofer 770 - Paper Guide Tubes; Additional Parts

Paper Guide / Camera System
Paper Guide Tubes
9
Preproofer x700 / x900 – HW Installation Manual 9-9
PP x700/x900 v1.7
Put a thin slot nut into the profile. Use the M5 screw
to fix the side holder to the profile.
The distance between the side holders are 1166mm,
measured from the outer side to the outer side of
the frame holders.
9.6 Paper Guide Tubes
9.6.1 Additional parts
Pos
Amount
Name
Dimension in mm
64
2
Aluminum tubes, 20mm diameter
1165
