Preproofer x700 / x900 – HW Installation Manual 6-7
PP x700/x900 v1.7
6.5.2 Open PCB Cover on the Epson Printer
Locate the cover and remove 4 screws.
6.5.3 Cable from Electronic Box
Put the white cable from the Electronic Box as
shown into the Printer.
