Set the Printers into the Stand
Wire the Control Panel Front Printer
8
Preproofer x700 / x900 – HW Installation Manual 8-1
PP x700/x900 v1.7
8 Set the Printers into the Stand
8.1.1 Additional Parts
Pos
Amount
Name
Dimension in mm
54
4
Aluminum Cylinder
20mm diameter x
23mm length
55
4
Screws M6 x 40
4
Washer M8 wide
