Preproofer 770 - Side Parts - Camera Holder BACK Printer; Parts Used

Paper Guide / Camera System
Side Parts - Camera Holder BACK Printer
9
Preproofer x700 / x900 – HW Installation Manual 9-3
PP x700/x900 v1.7
Mount the bracket as shown for the right holder.
9.2 Side Parts - Camera Holder BACK Printer
9.2.1 Parts used
Pos
Amount
Name
Dimension in mm
06
1
Camera holder BACK printer
07
1
Camera holder
58
2
Screw M5 x 10
