Preproofer 770 - Assembly Instructions; Frame Sides Assembly

Assembly
Frame Sides
5
Preproofer x700 / x900 – HW Installation Manual 5-1
PP x700/x900 v1.7
5 Assembly
5.1 Frame Sides
5.1.1 Additional Parts
Locate the following parts:
Pos
Amount
Name
Dimension in mm
23
4
Base plate for swivel caster
40 x 80
25
8
Allen screw with rounded head,
Fixes base plate to profile
M8 x 20
26
8
Slot nut
M8
