Assembly
Frame Sides
5
Preproofer x700 / x900
–
HW
Installation Manual
5-3
PP x700/x900 v1.7
5.1.3
M
ount the Pillar and Dist
ance Profile
T
ake for each side the two pillar pr
ofiles (Pos 2, blue
colored, 795 mm
) and the distance holder profile f
or
lower printer (Pos 4, b
lue colored, 650 mm
, 160 mm
height).
T
ake care to mou
nt the p
illars
correctly
. The
screw is
on
the outer side.
Pos 4
Pos 2
Pos 2
Pos 3
18
20
