Preproofer 770 - Frame Parts

4
Frame Setup
Frame Parts
4-2 Preproofer x700 / x900 – HW Installation Manual
PP x700/x900 v1.7
4.2 Frame Parts
Pos
Amount
Color
Name
Profile in mm
Length in mm
1
4
Cross-member for printer top /
bottom
40 x 80
2060
2
4
Pillar
40 x 80
795
3
2
Cross-member, 2 wheels mounted
40 x 80
1100
4
2
Cross-member bottom, distance
holder for lower printer
40 x 120
650
5
2
Cross-member top
40 x 80
810
6
2
Cross-member for frame
stabilization
40 x 80
1980
7
4
Distance holder for cross-member,
position 1. Also used to fix printer to
stand with bracket, position 27
40 x 40
305
8
4
Bracket for stabilization cross-
member
9
4
Base plate for swivel caster
40 x 80
10
4
Swivel caster, 75mm
