Position the first distance holder (Pos 8, brown
colored, 305 mm) 340 mm from the side frame.
Fix only the screw which goes to the profile labeled
“A”.
Position the second distance holder (Pos 8, brown
colored, 305 mm) 1285 mm from the first distance
holder profile.
Fix only the screw which goes to the profile labeled
“A”.
