Promise Technology Pegasus3 R4 User Manual

89
Managing the Pegasus3Pegasus3 Product Manual
Synchronization
Synchronization is automatically applied to logical drives when they are created. Synchronization
recalculates the redundancy data to ensure that the working data on the physical drives is properly in
sync.
Mouse-over on the logical drive, click the View button, and look under Logical Drive Information beside
the line that says Synchronized. A Ye s means the logical drive was synchronized. See “Viewing
Logical Drive Information” on page 125.
Making Synchronization Settings
To make Synchronization settings:
1. Click on the Background Activities icon.
2. Click the Settings button.
3. Click the Background Synchronization Rate dropdown menu and choose a rate:
• Low – Fewer system resources to Synchronization, more to data read/write operations.
• Medium – Balances system resources between Synchronization and data read/write
operations.
• High – More system resources to Synchronization, fewer to data read/write operations.
4. Click the Conrmbutton.
5. Click the X icon to close the background activities panel.
Synchronizaon

Promise Technology Pegasus3 R4 Specifications

General

Internal	No
Chassis type	Tower
Cooling type	Active
Device class	Small & Medium Business
Fan diameter	92 mm
Certification	CB, UL, cUL, TUV , BSMI, SPRING, BIS FCC, CE-EMC, VCCI, BSMI, RCM KCC
Product color	Black
LED indicators	Yes
Number of fans	1 fan(s)
Airflow (imperial)	70 cfm
Management platform	Pegasus Utility
Cable lock slot type	Kensington
RAID levels	0, 1, 1E, 5, 6, 10
Data transfer rate	40 Gbit/s
Storage drive size	3.5 \
Storage drive capacity	4000 GB
Storage drive interface	Serial ATA
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Total installed storage capacity	16 TB
Maximum supported storage capacity	- TB
Number of storage drives installed	4
AC input voltage	100-230 V
AC input frequency	50 - 60 Hz
Number of power supply units	1
Power supply unit (PSU) capacity	250 W
Thunderbolt version	3
Thunderbolt ports quantity	2
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %
Cables included	AC, Thunderbolt

Weight and Dimensions

Depth	188 mm
Width	248 mm
Height	195 mm
Weight	6800 g
