Promise Technology Pegasus3 R4/R6/R8
Pegasus Utility with Custom Settings
To use your own format settings, you must create your logical drives using the Wizard Advanced option
or create your logical drives manually, and you must UNcheck the Format box.
See “Creating a Disk Array and Logical Drive with the Wizard” on page 47 and
“Creating a Logical Drive Manually” on page 61.
To format your logical drives using the Pegasus Utility with your own settings:
1. In the Logical Drive list, mouse-over the logical drive you want to format, and click the Format
button.
2. Supply information as required:
• Optional:TypeadifferentnameintotheVolumeNameeld.
• Choose a partition from the Partition Type dropdown menu.
• Choose a format type from the Format Type dropdown menu.
• For Mac computers, the default GPT Format partition and the default
• Journaled HFS+ format are recommended.
3. Click the Formatbutton.
WhenthePegasusUtilityhasnishedthepartitionandformatoperation,newremovable-driveicons,
each representing one logical drive, appear on your desktop (right).
When you see the icon, your logical drives are ready to use.

Promise Technology Pegasus3 R4 Specifications

General

Internal	No
Chassis type	Tower
Cooling type	Active
Device class	Small & Medium Business
Fan diameter	92 mm
Certification	CB, UL, cUL, TUV , BSMI, SPRING, BIS FCC, CE-EMC, VCCI, BSMI, RCM KCC
Product color	Black
LED indicators	Yes
Number of fans	1 fan(s)
Airflow (imperial)	70 cfm
Management platform	Pegasus Utility
Cable lock slot type	Kensington
RAID levels	0, 1, 1E, 5, 6, 10
Data transfer rate	40 Gbit/s
Storage drive size	3.5 \
Storage drive capacity	4000 GB
Storage drive interface	Serial ATA
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Total installed storage capacity	16 TB
Maximum supported storage capacity	- TB
Number of storage drives installed	4
AC input voltage	100-230 V
AC input frequency	50 - 60 Hz
Number of power supply units	1
Power supply unit (PSU) capacity	250 W
Thunderbolt version	3
Thunderbolt ports quantity	2
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %
Cables included	AC, Thunderbolt

Weight and Dimensions

Depth	188 mm
Width	248 mm
Height	195 mm
Weight	6800 g
