6400 OPERATING MANUAL
7.2 PRINT CURRENT FAULTS
• Function : This option allows the user to print any ‘Faults’ that are currently on the system.
• Selecting Option : To select this option , press the number ‘1’ key from the ‘Printer menu’.
Once selected, the printer will print the ‘Current Faults’ in the following format :-
***************************
List of Current Faults
20 Aug 2006, 10:15:54
***************************
Time 20 Aug 2006 , 09:49:31
LOOP FAULT
Node X Loop X
**************************
• Exiting Option : Pressing the ‘0’ or ‘ESC’ key , will EXIT ‘Print current faults’ and return to the ‘Main menu’
options. This will NOT stop the printer from printing the ‘List of current faults’. To stop the
printer, select option number ‘7’ from the ‘Printer menu’.
Time & date the fault
occurred.
The date & time when the
list of current faults was
printed.
Displays the Node /
Loop & location of the
fault
Note - If text has been
assigned to the node, then
the text will be displayed
rather than the node & loop
No
Fault description
