93-310-10 Issue 4 Rev 5 Page 77 of 88 Copyright Protec Fire Detection PLC
6400 OPERATING MANUAL
F
F
U
U
N
N
C
C
T
T
I
I
O
O
N
N
B
B
U
U
T
T
T
T
O
O
N
N
S
S
16.1 - FUNCTION BUTTONS
On the front of a repeat panel, there are 5 function buttons (only 3 on the LCD panel) as follows: -
MENU SELECT MUTE
SILENCE RESET
(Only available on the RDN)
Menu Button - Pressing this button allows access to the Repeat panels ‘Menu options’ (refer to Section 16.1 for
details).
Select Button - This button is primarily used when in the ‘Menu options’.
Mute - This button will stop the fault / fire buzzer on the Repeat panel only.
Silence - Pressing this button will silence any currently active ‘ALARMS’.
Reset - Pressing this button will reset any active fire events on the network. This button will only function
once the alarms have been silenced
