93-310-10 Issue 4 Rev 5 Page 85 of 88 Copyright Protec Fire Detection PLC
6400 OPERATING MANUAL
P
P
R
R
I
I
N
N
T
T
I
I
N
N
G
G
23.1 PRINTING - RDN Only
Note – Printing is only available if the repeat panel is configured to be used with a printer.
On the RDN there is the option of being able to print events. There are three printing options as follows: -
1 Print current fires
2 Print current faults
3 Print current disablements
N.B. The user can only print faults and disablements when the repeat panel has been configured to show faults and
disablements respectively. Obviously, the panel needs to have been configured to use a printer also.
To print one of the three options above, the user needs to enter the menus by pressing the ‘MENU’ button. The ‘MUTE’
button should then be pressed to cycle through the available options until the upper LCD shows the required option as
shown below: -
When the required option is shown, press the ‘SELECT’ button to commence printing.
Once printing has been started, printing will continue until all the events of the chosen type have been printed. Printing
can be cancelled at any time by pressing the ‘SELECT’ button (when outside of the menus).
N.B. Refer to Section 17.2 for instructions on how to select menu options.
MENU OPTIONS :-
PRINT CURRENT FIRES / ALARMS
Displays the menu
option for selection
