FIGURE 2 - Loop Processing Node (LPN)
Status LEDs
Door Lock
Printer Output
Control Buttons
1.2 6400 NODE DESCRIPTIONS
1.3 DCN NODE
LED Display LCD Display
QWERTY Keypad Arrow keys Numeric Keypad
SOUND ALARMS Pressing this button will operate ‘Alarm outputs’ on the network as programmed when the system was
commissioned.
SILENCE Pressing this button will Silence ALL ‘Alarm outputs’ on the network.
ACCEPT Pressing this button will accept any fire / fault events , and mute the fault buzzer.
RESET Pressing this button will reset ALL fire indications , and release any ‘Control outputs’ .
1.4 LPN NODE
FIGURE 1
