13.1 THRESHOLD LEVELS FOR 6000 SERIES ANALOGUE DEVICES
ANALOGUE THRESHOLD LEVELS (T
hist
)
FAULT NORMAL
OPTICAL SMOKE SENSOR
0 – 15, 141 – 255 16 – 140
IONISATION SMOKE SENSOR
0 – 15, 151 – 255 16 – 150
TEMPERATURE SENSOR
0 – 25, 250 – 255 26 – 249
OPTICAL HEAT SENSOR – Optical channel
0 – 15, 141 - 255 16 – 140
OPTICAL HEAT SENSOR – Heat channel
0 – 25, 250 – 255 26 – 249
CO HEAT SENSOR – CO channel
0 – 19, 151 - 255 20 - 150
CO HEAT SENSOR – Heat channel
0 – 24, 251 - 255 25 – 250
OPTICAL HEAT CO SENSOR – Optical channel
0 – 34, 91- 255 35 – 90
OPTICAL HEAT CO SENSOR – Heat channel
0 – 24, 251 - 255 25 – 250
OPTICAL HEAT CO SENSOR – CO channel
0 – 19, 151 - 255 20 - 150
13.2 THRESHOLD LEVELS FOR 6000 SERIES DIGITAL DEVICES
THRESHOLD LEVELS (T
1
)
SENSITIVITY FAULT NORMAL FIRE
MCP
N/A 0 85 220
ZONE ALARM INTERFACE
N/A 17 - 22 85 219 - 220
MICCO
N/A 17 - 18 85 220
SOUNDERS & OTHER OUTPUT DEVICES
N/A 0 85 N/A
Notes :-
1. T
hist
is shown on the analogue value
graph (see section 9.3).
2. Fire levels are calculated by
algorithms within the system (see
section 9.3). These fire levels change
with the device sensitivity.
3. Each channel of a multi-channel
device such as the Optical heat has
the same sensitivity.
