21.1 VIEW CURRENT FAULTS
Note – Fault events can only be viewed if the repeat panel is configured to show faults.
In the event of a fault activation occurring the repeat panel’s audible buzzer will sound (1 second on / 1 second off). The
‘Fault‘ lamp will illuminate and the following will be displayed on the upper LCD: -
To view the fault events press the ‘MENU’ button and then using the ‘MUTE’ button scroll through the ‘Menu options’
until the upper LCD displays: -
When the ‘View current faults’ is shown, press the ‘SELECT’ button and the following options will be displayed:-
• Viewing events : To scroll through the fault events, press the ‘SELECT’ button while the cursor is flashing on
the ‘View next fault’. Once pressed the ‘Fault Event Number’ will increment and the lower
LCD will display the new event details. Pressing ‘Mute’ will cycle through the options
described below :-
• Location text : The location text for the fault events can be displayed (if available), by selecting the ‘View
location text’ option when viewing the correct fault event number.
• Show Details : The Fault details (Node, Loop, Zone etc) for the fault events can be displayed by selecting
the ‘Show details’ option when viewing the required fault event number.
• 30 Faults Events : The repeat panels can each store a maximum of 30 fault events.
• Exiting option : To return to the previous menu level, press the ‘MENU’ button.
N.B. Refer to Section 17.2 for instructions on how to select menu options.
xx Faults 20 May 2006, 10:17
PROTEC FIRE DETECTION PLC
MENU OPTIONS :-
VIEW CURRENT FAULTS
XX Faults : Fault Event Number XX
VIEW NEXT FAULT
20 Aug 06, 10:17:34 Fault description
Displays the fault event number.
1 = first event to occur.
Highest number = last event to occur.
