8.5.2 DISABLE / ENABLE FAULT LINK
• Function : This option allows the disablement and enablement of the Fault link.
Note - This option is able to disable the signal that is sent to the manned centre only if the
signal is connected to the dedicated ‘Fault link’ output terminals.
• Selecting Option : To select this option , press the number ‘2’ key from the ‘Disable outputs menu’ .
When this option is selected, the menu option will toggle between :-
2 Disable all Fault Links
and
2 Enable all Fault Links
• Disable all fire Links :To disable ‘All fault links’ press ‘2’ while the display is showing ‘Disable all fault
links’ , the panel buzzer will sound intermittently and the following disablement LED will
illuminate :-
• Buzzer mute : The panel buzzer can be muted by pressing ‘Accept’.
• Enable all fault Links :
To enable ‘All fault links’ press ‘2’ while the display is showing ‘Enable all fault
links’ . This will extinguish the ‘Disablement’ LED.
Disablement
