93-310-10 Issue 4 Rev 5 Page 80 of 88 Copyright Protec Fire Detection PLC
6400 OPERATING MANUAL
When the ‘View current fires’ is being displayed, press the ‘SELECT’ button, which will then display the following
options: -
• Viewing a fire event : To scroll through the fire events, press the ‘SELECT’ button while the cursor is
flashing on the ‘View next fire / alarm’ option. Once pressed, the ‘Event’ will increment
and the lower LCD will display the new event details. Pressing ‘Mute’ will cycle
through the options shown below :-
• Location text : To view the location text for fire events, the ‘View location text’ option should be
selected.
• Alarm text : To view the alarm text for fire events, the ‘View alarm text’ option should be selected.
• Show Details : To view the Fire details ( Node, Loop, Zone, etc.) for fire events, the ‘Show details’
option should be selected.
• 20 Fire Events : The repeat panels can each store a maximum of 20 fire events.
• Exit option : To return to the previous menu level, press the ‘MENU’ button.
N.B. Refer to Section 17.2 for instructions on how to select menu options.
XX Events : Event XX SYSTEM FIRE
VIEW NEXT FIRE/ALARM
Displays the event number.
1 = first event to occur.
Highest number = last event to occur.
To Next Page
