Quantum Scalar i40 User Manual

Chapter 6: Performing Library Operations
Unlocking and Opening the I/E Station
Quantum Scalar i40 and Scalar i80 User’s Guide 147
4 Within 30 seconds, open the I/E station by pulling outward on the
magazine bezel handle until the magazine stops moving.
If you do not open the magazine within 30 seconds, it locks and you
receive the following failure message.
Figure 27 I/E Station Locked
Message
5 When finished, push the magazine in completely.
The I/E station is now locked.
Web Client
1 Select Operations > I/E Station Unlock.
2 Sele
ct an I/E station to unlock and click Apply.
Note: Only closed I/E stations are listed.
3 Click Apply to confirm, and click OK.
The Progress Window displays. The Progress Window contains
information on the action, el
apsed time, and status of the
requested operation. Do one of the following:
•If Success appears in the Progress Window
, the I/E station was
unlocked. Click Close to close the Progress Window. The
operator panel displays the status Unlocking and then Idle.
•If Fa
ilure appears in the Progress Window, the I/E station did
not unlock.
4 Within
30 seconds, pull outward on the magazine bezel handle to
open the I/E station.
If you do not open the magazine within 30 seconds, it locks.

Quantum Scalar i40 Specifications

General

Power requirements	100 - 240 V AC, 50 - 60 Hz, 2.8/1.4 Amps
Power consumption (typical)	100 W
Expansion slots	25
Dimensions (WxDxH)	455 x 793 x 132 mm
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Media type	Tape Cartridge
Product type	Storage auto loader & library
Product color	Black

Weight and Dimensions

Weight	15800 g
