Quantum Scalar i40 - Figure 9 Operator Panel User Interface - Alternate Home Screen; Scalar I80

Chapter 3: Understanding the User Interface
Operator Panel
Quantum Scalar i40 and Scalar i80 User’s Guide 23
Figure 9 Operator Panel User
Interface - Alternate Home
Screen
Number of configured
I /E slots
Number of occupied
I /E slots
Scalar i40
Scalar i80
Number of occupied
I /E slots
Number of
configured I/E slots
Unlock I/E Station
Unlock bottom
I/E Station
Unlock top
I/E Station
