Quantum Scalar i40 - Space Requirements; Tools Required; Rack Mount Kit Contents

Chapter 9: Installing, Removing, and Replacing Components
Installing the Rack Mount Kit (Rail Kit)
230 Quantum Scalar i40 and Scalar i80 User’s Guide
Space Requirements See the following:
•
Physical Specifications on page 341 and
•
Air Clearance Requirements on page 343
Tools Required • Phillips screwdriver
• Magazine lock override tool — an op
ened paperclip, small
screwdriver, or other object (3.5 mm or less in diameter that will not
break off)
Rack Mount Kit
Contents
The following items are included in the rack mount kit:
Qty Figure Description
2
Shelf
2
Shelf Extender
16
Phillips head screw, countersunk (M5 x 10) – for
shelf assembly
