Quantum Scalar i40 - Figure 47 Installing the Rack Mount Shelves

Chapter 9: Installing, Removing, and Replacing Components
Installing the Rack Mount Kit (Rail Kit)
238 Quantum Scalar i40 and Scalar i80 User’s Guide
Figure 47 Installing the Rack
Mount Shelves
Left shelf
Right shelf
Washers
M4 x 12
screws
