Quantum Scalar i40 User Manual

Chapter 11: Troubleshooting
Interpreting LEDs
Quantum Scalar i40 and Scalar i80 User’s Guide 321
• Tape drives
• Power supplies
Front Panel LEDs There are two LEDs on the front panel, above the power button. They
function as follows:
LED Location Color Indicates
Power-on LED
(closest to
power
button)
Green Library power is ON.
Ticket indicator
LED
. (farthest from
power button)
Amber The LED is illuminated when at least
one open or unopened diagnostic
ticket exists.
Figure 77 Front Panel LEDs
Ticket indicator LED
Power-on LED

Quantum Scalar i40 Specifications

General

Power requirements	100 - 240 V AC, 50 - 60 Hz, 2.8/1.4 Amps
Power consumption (typical)	100 W
Expansion slots	25
Dimensions (WxDxH)	455 x 793 x 132 mm
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Media type	Tape Cartridge
Product type	Storage auto loader & library
Product color	Black

Weight and Dimensions

Weight	15800 g
