Quantum Scalar i40 User Manual

Chapter 6: Performing Library Operations
Releasing Magazines
Quantum Scalar i40 and Scalar i80 User’s Guide 149
Releasing Magazines
via the User Interface
Use this method when the library is turned ON.
Operator Panel
1 Select Actions > Magazine.
2 Select
a magazine and press Release.
Note: Only closed magazines are listed.
3 Wait until the robot unlocks the magazine and the screen displays
the Magazine is now unlocked message (see Figure
28).
Figure 28 Magazine Unlocked
Message
4 Pull outward on the magazine bezel handle to slide the magazine
out as far as you wish, or remove it completely. Once you slide the
magazine back into the slot all the way, it locks again automatically
If
you do not open the magazine within 30 seconds, it locks and you
receive the following failure message.
Figure 29 Magazine Locked
Timer Message

Quantum Scalar i40 Specifications

General

Power requirements	100 - 240 V AC, 50 - 60 Hz, 2.8/1.4 Amps
Power consumption (typical)	100 W
Expansion slots	25
Dimensions (WxDxH)	455 x 793 x 132 mm
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Media type	Tape Cartridge
Product type	Storage auto loader & library
Product color	Black

Weight and Dimensions

Weight	15800 g
