Quantum Scalar i40 - Figure 63 Reinstalled Components

Chapter 9: Installing, Removing, and Replacing Components
Replacing the Chassis
Quantum Scalar i40 and Scalar i80 User’s Guide 267
Figure 63 Reinstalled
Components
Ethernet cable in LEFT
SCB port
Fibre Channel cables in LEFT
port of full-height tape drives
Power
supply cord
Full-height tape drives
Half-height tape drives
Power
supply cord
Ethernet cable in LEFT
SCB port
Tape drive cables
