Quantum Scalar i40 User Manual

Chapter 9: Installing, Removing, and Replacing Components
Installing the Rack Mount Kit (Rail Kit)
Quantum Scalar i40 and Scalar i80 User’s Guide 231
8 T- nut (M5) – for shelf assembly
8 total
Rail adapter – 4 each of two types are included. You
need 4 for installation; choose the type appropriate
for your rack (for more information, see Figure
45
on page 235)
8
Phillips head screw, countersunk (M4 x 12) – for
mounting shelves to rack
8
Washer, countersunk – for mounting shelves to rack
4
Clip nut (M5 x 0.8) – for securing library in rack
4
Cage nut (M5) – to secure library to rack. Used in
racks with square or round non-threaded holes.
Qty Figure Description

Quantum Scalar i40 Specifications

General

Power requirements	100 - 240 V AC, 50 - 60 Hz, 2.8/1.4 Amps
Power consumption (typical)	100 W
Expansion slots	25
Dimensions (WxDxH)	455 x 793 x 132 mm
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Media type	Tape Cartridge
Product type	Storage auto loader & library
Product color	Black

Weight and Dimensions

Weight	15800 g
