Rapid 4044 - Figure 68: Air Handler Styles

SECTION 19: ELECTRICAL
93 of 154
FIGURE 68: Air Handler Styles
Bottom
Discharge
Optional Motorized Inlet Damper
100%
Outside Air
Optional Motorized Inlet Damper
Bottom
Return
20%
Outside Air
80%
Return Air
Bottom
Discharge
Bottom
Discharge
Bottom
Return
20%
Outside Air
80%
Combined
Outside Air
and Bypass Air
Bottom
Discharge
20%
Outside Air
80%
Combined
Outside Air and
Recirculated Air
MUA - MAKE UP AIR (All Models) FR - FIXED RETURN (All Models)
AM -AIR MANAGEMENT (All Models) VAV - VARIABLE AIR VOLUME (All Models)
