SECTION 5: SPECIFICATIONS
25 of 154
Table 18: Fan Selection Chart (continued)
* MUA configuration only.
** AM requires high velocity return air damper.
¤ Class II wheels
CF= Consult Factory
IMPORTANT NOTES:
Sound levels are in dBA at 5' from the supply air opening. This figure does not account for attenuation,
additional noise or directivity factors. More horsepower required includes both the running horsepower and
the starting torque requirements. Horsepower can be greater than the standard fan curve charts. Brake
horsepower does not include drive losses. For external static pressure greater than 2", contact your local
representative or Rapid Engineering LLC. For operation in altitudes exceeding 2000' above sea level, contact
the factory. The recommended motor horsepowers shown for the Fan Selection Chart in the 0 in. wc external
static pressure column include fan and burner static pressures only (internal equipment static pressure).
Other cabinet options could add static pressure and should be included in the external static pressure used
to select motor horsepower. See the Static Pressure Drops in Table 20, Page 41 for the external static
pressu
res that should be added for selected options.
Airflow Cubic
Feet per
Minute (CFM)
Model
Discharge Velocity
Feet per
Minute (FPM)
Required Motor Horse Power (HP)
@ Noted External Static Pressure
(in wc)
Brake Horse Power (HP)
@ Noted External Static Pressure
(in wc)
dBA Decibel @
Noted External
Static Pressure
(in wc)
0 0.25 0.5 0.75 1 1.25 1.5 1.75 2 0 0.25 0.5 0.75 1 1.25 1.5 1.75 2 0
55,000 4060** 2,037 20 25 25 25 30 30 40 40 40 18.1 20.0 21.9 23.9 26.0 28.1 30.1 32.3 34.6 83
55,000 4066 1,741 20 20 20 25 25 30 30 40 40 15.0 17.1 19.2 21.2 23.5 25.7 28.1 30.4 32.8 80
55,000 4073 1,600 20 20 25 25 30 30 30 CF CF 16.1 18.4 20.8 23.2 25.6 28.2 30.8 CF CF 75
60,000 4060** 2,222 25 25 30 30 40 40 40 40 40 22.0 24.1 26.2 28.3 30.5 32.7 35.0 37.3 39.5 85
60,000 4066 1,899 20 25 25 25 30 30 40 40 40 18.1 20.2 22.4 24.7 27.0 29.4 31.8 34.3 36.9 81
60,000 4073 1,745 20 25 25 30 30 40 40 40 40 18.6 21.0 23.5 26.1 28.6 31.3 34.1 36.9 39.7 77
60,000 4080 1,241 20 20 25 25 30 CF CF CF CF 16.5 19.1 21.7 24.5 27.4 CF CF CF CF 72
65,000 4066 2,057 25 25 30 30 40 40 40 40 50 21.6 23.9 26.2 28.6 31.1 33.6 36.1 38.8 41.4 83
65,000 4073 1,891 25 25 30 30 40 40 40 50 50 21.3 23.8 26.5 29.2 31.9 34.7 37.6 40.5 43.5 79
65,000 4080 1,345 20 25 25 30 40 40 CF CF CF 18.5 21.3 24.0 27.0 30.2 33.0 CF CF CF 74
70,000 4066** 2,215 30 30 40 40 40 40 50 50 50 25.5 27.9 30.4 33.0 35.6 38.2 40.9 43.5 46.4 85
70,000 4073 2,036 25 30 30 40 40 40 50 50 50 24.5 27.1 29.8 32.7 35.6 38.5 41.5 44.5 47.6 81
70,000 4080 1,448 25 25 30 30 40 40 40 50 CF 20.7 23.6 26.6 29.5 32.7 35.9 39.1 42.4 CF 76
75,000 4066** 2,374 30 40 40 40 50 50 50 50 60 30.0 32.6 35.2 37.9 40.6 43.4 46.2 49.1 52.0 87
75,000 4073 2,182 30 40 40 40 40 50 50 50 60 27.9 30.7 33.6 36.4 39.5 42.6 45.7 48.9 52.1 83
75,000 4080 1,552 25 30 30 40 40 40 50 50 50 23.2 26.3 29.4 32.5 35.8 39.1 42.4 45.9 49.4 78
75,000 4089 1,552 25 25 30 40 40 CF CF CF CF 21.3 24.5 27.9 31.3 34.8 CF CF CF CF 73
80,000 4066** 2,532 40 40 50 50 50 50 60 60 60 35.1 37.8 40.6 43.4 46.3 49.2 52.1 55.1 58.2 88
80,000 4073 2,327 40 40 40 50 50 50 60 60 60 31.7 34.6 37.6 40.7 43.7 47.0 50.3 53.6 56.9 85
80,000 4080 1,655 30 30 40 40 40 50 50 50 60 26.0 29.0 33.9 35.5 38.9 42.3 45.8 49.4 52.9 79
80,000 4089 1,655 25 30 40 40 40 50 CF CF CF 23.5 26.9 30.3 33.9 37.6 41.3 CF CF CF 75
85,000 4073** 2,473 40 40 50 50 50 60 60 60 75 36.0 39.1 42.3 45.5 48.7 51.9 55.4 58.8 62.4 86
85,000 4080 1,759 30 40 40 40 50 50 50 60 60 29.0 32.2 35.5 38.9 42.4 46.0 49.6 53.2 57.1 81
85,000 4089 1,759 30 30 40 40 50 50 50 60 CF 25.8 29.4 33.0 36.6 40.4 44.3 48.3 52.3 CF 76
90,000 4073** 2,618 50 50 50 60 60 60 75 75 75 40.7 43.9 47.2 50.5 53.9 57.4 60.7 64.3 68.0 87
90,000 4080 1,862 40 40 40 50 50 50 60 60 75 32.4 35.7 39.2 42.6 46.3 50.0 53.8 57.6 61.5 82
90,000 4089 1,862 30 40 40 40 50 50 60 60 60 28.3 32.0 35.8 39.6 43.5 47.5 51.6 55.8 60.0 78
95,000 4073* 2,764 50 50 60 60 60 75 75 75 75 45.9 49.2 52.6 56.1 59.6 63.2 66.8 70.5 74.1 88
95,000 4080 1,966 40 40 50 50 60 60 60 75 75 35.9 39.4 43.0 46.6 50.3 54.2 58.1 62.1 66.1 84
95,000 4089 1,966 40 40 40 50 50 60 60 60 75 31.3 35.0 38.9 42.9 46.9 51.0 55.3 59.5 64.0 79
100,000 4073** 2,909 50 50 50 60 60 75 75 75 75 41.2 44.8 48.5 52.3 56.0 60.0 64.1 68.3 72.5 89
100,000 4080 2,069 40 50 50 60 60 60 75 75 75 39.8 43.5 47.2 51.0 54.9 58.7 62.8 66.9 71.1 85
100,000 4089 2,069 40 40 50 50 60 60 60 75 75 34.3 38.1 42.2 46.2 50.5 54.7 59.0 66.2 68.0 80
110,000 4080 2,279 50 60 60 60 75 75 75 100 100 46.2 50.4 54.4 59.4 64.0 68.7 73.6 78.5 83.5 88
110,000 4089 2,276 50 50 50 60 60 75 75 75 100 41.1 45.2 49.5 53.8 58.3 62.8 67.5 72.2 76.9 83
120,000 4080** 2,483 60 75 75 75 100 100 100 100 100 57.0 61.6 66.1 70.9 75.9 80.9 86.1
91.2
5
96.5 90
120,000 4089** 2,483 50 60 60 75 75 75 100 100 100 49.0 53.4 57.9 62.5 67.1 71.9 76.8 81.9 86.9 85
130,000 4089** 2,690 60 75 75 75 100 100 100 100 100 58.0 62.7 67.5 72.4 77.4 82.2 87.4 92.7 98.0 87
150,000 4089** 3,103 100 100 100 100 125 125 125 125 125 80.0 85.3 90.6 96.0
101.
5
107.
1
112.
8
118 .
5
124.
4
91
