Rapid 4044 - Caulking an Vertical Air Handler; Figure 22: Caulking a Standard Vertical Air Handler

SECTION 7: AIR H ANDLER A SSEMBLY
35 of 154
7.3 Caulking an Vertical Air Handler
FIGURE 22: Caulking a Standard Vertical Air Handler
NOTE: Sections may vary as shown.
SHEETMETAL CHANNEL OR ANGLE IRON FRAME
MUST BE ALIGNED ON ALL SECTIONS.
RAIN SKIRT ON
OUTDOOR AIR HANDLER
"A
Ó
"AÓ
"AÓ
"AÓ
LEGS
"A"
LIFTING LUGS
"A"
"A"
FIELD ATTACHMENT
"A"
"A"
RAIN SKIRT ON
OUTDOOR AIR HANDLER
FIELD ATTACHMENT
SHEETMETAL CHANNEL OR
ANGLE IRON FRAME MUST BE
ALIGNED ON ALL SECTIONS.
LIFTING LUGS
LEGS
"A" TYPE JOINT:
SEAL WITH HEAVY
BEAD OF CALUKING
(PROVIDED BY OTHERS)
