SECTION 10: LEG MOUNTING
Vertical MUA, FR, AM and 4024-4049 VAV units require a quantity of four legs. Vertical 4054-4089 VAV units
without an OA filter section require a quantity of six legs (all of the same height). Vertical 4054-4089 VAV
units with an OA filter section require a quantity of six legs (four legs of the same height and two legs at a
height of 30" taller than the first four). Consult Factory if height of additional two legs exceed the standard leg
offerings. Horizontal 4024-4049 require a minimum quantity of four legs. Horizontal 4054-4089 require a
minimum quantity of eight legs. For every additional section (ie. mix box, coil, etc.) beyond the basic
horizontal unit except for inlet hoods and outside air filter sections, an additional four legs must be added.
Crush Hazard
Use proper lifting
equipment and
practices.
Falling Hazard
Use proper safety
equipment and prac-
tices to avoid falling.
Severe Injury Hazard
Use proper lifting
practices and equip-
ment.
Equipment and
accessories are
heavy.
Cut/Pinch Hazard
Wear protective gear
during installation,
operation and
service.
Edges are sharp.
WARNING
Failure to follow these instructions can result in death, injury or property damage.
