4000-SERIES INSTALLATION, OPERATION AND SERVICE MANUAL
126 of 154
21.6 Safety Shut Off Valve Check
After the initial start up and gas pressure adjustment,
verify gas soundness of each SSOV (Safety Shut Off
Valve). This check must be repeated after the first
100 hours of operation.
21.7 Temperature Control System Calibration
The temperature control system components are
factory calibrated to a base resistance so that
component replacement will not upset the system
calibration. If the temperature control system should
require field calibration, refer to the provided
temperature control amplifier product information
sheet.
Table 38: Maximum Temperature Rise
SC11 Signal
Conditioner
Set BMS to max fire or
remove input wires from
terminals #6 and #5 and
connect a 9VDC battery to
the signal conditioner
Remove from terminal
#1 on the
signal conditioner
Series 94
Disconnect selector ribbon
cable from the amplifier.
Remove wire from ter-
minal #2 on the ampli-
fier
Series MP2
Set system to maximum
temperature
Remove wire from ter-
minal #2 on the amplifer
Model
Natural Gas LPG
°F °C °F °C
2005 90 50 80 44.5
2010 - 2030 110 61.1 90 50
