4000-SERIES INSTALLATION, OPERATION AND SERVICE MANUAL

28 of 154

6.2 Lifting a Horizontal Air Handler

FIGURE 15: Lifting a Horizontal Air Handler Filter Section and Options (Model 4024 - 4049)

FIGURE 16: Lifting a Horizontal Air Handler with Options (Model 4054 - 4089)

LIFTING SLINGS

END VIEW

CL CR

CRANE OR HELICOPTER CABLE

FAN

SECTION

BURNER

SECTION

FILTER

SECTION

FILTER MIX BOX

TRANS, EVAP &

FILTER SECTION

INLET

PLENUM

SPREADER BAR

END VIEW

CL CR

FILTER MIX BOX

TRANS, EVAP &

FILTER SECTION

INLET

PLENUM

NOTE: FOR MODELS 4080-4089, ACCESS DOOR IS ON BURNER SECTION.

LIFTING SLINGS

FAN

SECTION

BURNER

SECTION

FILTER

SECTION
