19.9 Safety Systems
Safety systems are required for proper performance of the air handler. The air handler shall not be permitted
to operate with any safety system disabled. If a fault is found in any of the safety systems, then the system
shall be repaired only by a contractor qualified in the installation and service of gas fired heating equipment,
using only components that are sold and supplied by Rapid Engineering LLC. Refer to Page 81, Table 31 for
a brief description of each safety device, its location and its switching voltage.
Table 31: Safety Systems
Safety Controls Location Voltage
Manual Reset High-Temp Limit (All Models) Blower Discharge 120
Pressure Switches (All Models) Air Handler Control Enclosure 120
Flame Control (All Models) Air Handler Control Enclosure 120
Supply Air Temperature Monitor (All Models) Blower Discharge 24
