4000-SERIES INSTALLATION, OPERATION AND SERVICE MANUAL

56 of 154

FIGURE 44: Service Platform for a Horizontal Air Handler

CONTROLS

RIGHT

3/8" BOLT

FIELD JOINT

WHEN REQUIRED

SERVICE PLATFORM

SUPPORT CHANNEL

3/8" BOLTS

SAFETY CHAIN

FRONT RAILING

SWAY TAB

SUPPORT RODS

DOUBLE NUTTED

LIFTING EYE

AIR HANDLER

SUPPORT CHANNEL

ACCESS SIDE RAILING

SIDE RAILING

FIELD ASSEMBLY

HOLES FOR 3/8" BOLTS

SUPPORT ROD HOLES

(by others)

TEK SCREW IN FIELD.

SPLICE LOCATED ON

4044-4089 MODELS ONLY

SIDE RAILING 4 PCS ASSEMBLY

FRONT

RAILING

INLET VIEW

RIGHT CONTROLS

Detail A: Models 4073 - 4089

Detail A: Models 4024 - 4066
