4000-SERIES INSTALLATION, OPERATION AND SERVICE MANUAL

128 of 154

FIGURE 78: M611 Valve

FIGURE 79: Regulator (2005)

Low Fire Adjustment

(under cap)

Gas Inlet

Gas Outlet

NOTE: Modulating only.

IN

PSI

2

OFF

ON

Outlet Pressure

Tap-1/8 NPT

Inlet Pressure

Tap-1/8 NPT

Regulator

Adjustment Below

(High Fire Adjustment Cap)

Gas FlowGas Flow
