Rapid 4044 - Figure 40: Inlet Hood Without Filters (4054-4089); Figure 41: Inlet Hood with Permanent Filters

SECTION 12: INLET H OODS
53 of 154
FIGURE 40: Inlet Hood without Filters (4054-4089)
FIGURE 41: Inlet Hood with Permanent Filters
Roof
Tape
Field Joint
Properly
Caulk
Notes:
(1) Failure to properly caulk the
field joints will allow water
to enter the air handler
(2) All parts mounted to inlet end
to be attached with 3/8" bolt
and flat washers.
(3) All other parts bolted together
with 5/16" bolts, flat washer,
and lock nut.
(4) All dimensions & weights are
subject to change without
notice & should not be used
for construction unless certified.
Typ. Assembly
Nut Inserts
Rapid recommends assembling
inlet hood parts to the air
handler in the following
sequence by item #:
8, 9, 16, 7, 5, 6, 4, 2, 1, 10, 11, 12
10
10
11
FILTER RAILS
TOP FILTER RAIL
DescriptionDetail
12
BOTTOM PAN & RAIL
13
L INLET HOOD GUTTER
14
15
FILTER CLIPS
16
TEK SCREWS
17
RAIL HARDWARE
18
19
FILTER SPACERS
20
R INLET HOOD GUTTER
ISOMETRIC VIEW
FILTER SPACER
REQUIRED ON SOME
MODELS
11
12
13
14
15
16
FILTERS
40600672
40600673
8
1
QtyASM/Part #
40600674 1
40600674 1
40600675 1
20900 4
20541 30
20699 14
20538 14
--
20596 8
MODEL 36
40620618
40620619
8
1
QtyASM/Part #
40620620 1
40620621 1
40620621 1
20900 8
20541 30
20699 14
20538 14
--
20596 4
MODEL 40
40600641
40600642
8
1
QtyASM/Part #
40600643 1
40600644 1
40600644 1
20900 8
20541 30
20699 12
20538 12
--
09701 12
MODEL 44
40504206-7
40504206-8
10
1
QtyASM/Part #
40504206-9 1
40504206-12 1
40504206-12 1
20900 10
20541 50
20699 16
20538 16
40504206 5
20596 20
MODEL 49
40620418-19
40620418-20
12
1
QtyASM/Part #
40620418-21 1
40620418-22 1
40620418-22 1
20900 12
20541 50
20699 22
20538 22
40620418-23 1
20596 24
MODEL 54
40630445
40630446
12
1
QtyASM/Part #
40630447 1
40630448 1
40630449 1
20900 12
20541 50
20699 24
20538 24
--
20596 30
MODEL 60
437345
437346
12
1
QtyASM/Part #
437347 1
437348 1
437349 1
20900 12
20541 50
20699 20
20538 20
--
20596 12
MODEL 66
40501125-7
40501125-8
5
1
QtyASM/Part #
40501125-9 1
40501125-12 1
40501125-12 1
20900 12
20541 50
20699 20
20538 20
-1
20596 36
MODEL 73
40600529-12
40600529-13
14
1
QtyASM/Part #
40600529-14 1
40600529-15 1
40600529-16 1
20900 14
20541 50
20699 30
20538 30
-1
77500 49
MODEL 80/89
EXPLODED VIEW
ASSEMBLY INSTRUCTIONS
· ASSEMBLE INLET HOOD PARTS LISTED IN EXPLODED VIEW #7,8,9,14 TO AIR HANDLER WITH
3
8
" FLAT
WASHERS AND
3
8
X 1 BOLTS.
· BUTYL ROPE CAULKING IS SUPPLIED AND SHOULD BE APPLIED BETWEEN EACH SIDE AND ROOF PANELS TO INSURE A WATER TIGHT SEAL, 3" WIDE ZIP
TAPE IS SUPPLIED AND SHOULD BE USED ACROSS EACH ROOF JOINT AS SHOWN.
· BOLT ITEMS #4,5,6 WITH
5
16
" HARDWARE TO ITEM #7,8,9 PREVIOUS MOUNTED.
· ITEMS #1,2 & 3 ARE THEN BOLTED TO ITEMS #4,5 & 6.
· INTERIOR GUSSET ITEMS ARE MOUNTED ON THE INSIDE OF HOOD TO SIDE WALL PANELS #5 & 6 AND #4 ROOF PANEL.
· HORIZONTAL BRACE IS MOUNTED TO #5 & 6 ON INTERIOR OF HOOD FOR CENTER SUPPORT.
· ITEM #13 & 14 RAIN GUTTERS MOUNT TO TAPERED EDGE OF HOOD, MOUNTING FLANGE TO THE INSIDE OF HOOD AND 2" FLANGE WITH BE TO THE
OUTSIDE AS SHOWN.
· ITEM #11 TOP FILTER RAIL MOUNTS TO ROOF OF INLET HOOD ITEM #1 WITH ITEM #16 TEK SCREWS.
· ITEMS #10 DUAL FILTER RAILS MOUNT TO ITEMS #13 & 14 WITH #10-24 HARDWARE.
· ITEMS #15 FILTER CLIP RETAINER ARE FASTENED TO ITEMS #13 & #14 WITH TEK SCREWS.
· SOME MODELS REQUIRE FILTER SPACER ITEM #19 TO COMPLETE ROW OF FILTERS.
7
8
9
5
6
4
1
2
3
14
10
14
13
13
ITEM #11 TEK SCREWS
TO THE OUTSIDE FLANGE
OF ITEM #1
FILTER RAILS ITEMS #10
MOUNT TO ITEMS #13 & 14 WITH
#10-24 HARDWARE
SOME MODELS REQUIRE FILTER
SPACER #19 (SEE CUTTING LIST)
17
FILTER CLIPS ARE
TEK SCREWED TO THE
OUTSIDE FLANGE OF ITEM #13
& #14 ON BOTH SIDE OF HOOD.
3" WIDE ZIP TAPE, SUPPLIED
FOR EACH ROOF JOINT.
EACH VERTICAL AND HORIZONTAL ROOF JOINT SHOULD
BE CAULKED WITH BUTYL TAPE THAT IS SUPPLIED
WITH INLET HOOD, TO INSURE A WATER TIGHT SEAL.
17 18
ASSEMBLY INSTRUCTIONS
· STANDARD INLET HOOD INSTRUCTION #40004504 (PG.17) FOR INSTRUCTIONS ON CAULKING
PRIOR TO ASSEMBLY.
· REFER TO ASSEMBLY DRAWING PACKAGED WITH INLET HOOD.
· INLET HOODS (4024-4049) ARE 6-PIECES & (4054-4089) 12-PIECES
· INLET HOODS 4054-4089 HAVE INTERNAL CORNER BRACES AND HORIZONTAL CROSS MEMBERS.
21
66512 4 66512 8 - - - - - - - - 66512 18 - - - -
40630297
40630298
4
1
QtyASM/Part #
40630299 1
40630301 1
40630300 1
20900 4
20541 10
20699 8
20538 8
40630302 4
20596 4
MODEL 24
--
20 21
FILTERS
RAIL HARDWARE
19
40600671 40620617 40600640 40504207 40620417 40630444 40437344 40501124 -40630296
Models
Assembly Reference
INLET HOOD FILTER HARDWARE, HARDWARE FOR INLET HOOD ASSEMBLY IS NOT LISTED HERE.
20 21
19
80/89 EXAMPLE
BOTTOM PAN VIEW
12
17
14
8
GUSSETS
