Renesas M16C Series User Manual

UART0 to UART2
M30240 Group
Rev.1.00 Sep 24, 2003 Page 86 of 360
Table 1.25: Specifications of Clock synchronous serial I/O mode
Note 1: “n” denotes the value 00
16
to FF
16
that is set to the UART bit rate generator.
Note 2: The UARTi receive buffer has the next data written when an overrun error occurs. Note: the UARTi receive interrupt
request bit is set to “0”.
Item Specification
Transfer data format •Transfer data length: 8 bits
Transfer clock
•When internal clock is selected (bit 3 at addresses 03A0
16
, 03A8
16
, 0378
16
= “0”):
fi/2(n+1) (Note 1) fi = f1, f8, f32
•When external clock is selected (bit 3 at addresses 03A0
16
, 03A8
16
, 0378
16
= “1”):
Input from CLKi pin (Maximum 5 Mbps.)
Transmission/reception
control
CTS
function/RTS function/CTS, RTS function chosen to be invalid
Transmission start
condition
•To start transmission, the following requirements must be met:
Transmit enable bit (bit 0 at addresses 03A5
16
, 03AD
16
, 037D
16
) = “1”
Transmit buffer empty flag (bit 1 at addresses 03A5
16
, 03AD
16
, 037D
16
) = “0”
When CTS function selected, CTS input level = “L”
•Furthermore, if external clock is selected, the following requirements must also be met:
CLKi polarity select bit (bit 6 at addresses 03A4
16
, 03AC
16
, 037C
16
) = “0”: CLKi input level = “H”
CLKi polarity select bit (bit 6 at addresses 03A4
16
, 03AC
16
, 037C
16
) = “1”: CLKi input level = “L”
Reception start condition
•To start reception, the following requirements must be met:
Receive enable bit (bit 2 at addresses 03A5
16
, 03AD
16
, 037D
16
) = “1”
Transmit enable bit (bit 0 at addresses 03A5
16
, 03AD
16
, 037D
16)
= “1”
Transmit buffer empty flag (bit 1 at addresses 03A5
16
, 03AD
16
, 037D
16
) = “0”
•Furthermore, if external clock is selected, the following requirements must also be met:
CLKi polarity select bit (bit 6 at addresses 03A4
16
, 03AC
16
, 037C
16
) = “0”: CLKi input level = “H”
CLKi polarity select bit (bit 6 at addresses 03A4
16
, 03AC
16
, 037C
16
) = “1”: CLKi input level = “L”
Interrupt request
generation timing
•When transmitting
Transmit interrupt cause select bit (bits 0, 1 at address 03B0
16
, bit 4 at address 037D
16
) = “0”:
Interrupts requested when data transfer from UARTi
Transmit interrupt cause select bit (bits 0, 1 at address 03B0
16
, bit 4 at address 037D
16
) = “1”:
Interrupts requested when data transmission from
•When receiving
Interrupt requested when the data transfer from the UARTi receive register to the UARTi receive
buffer register is complete.
Error detection
•Overrun error (Note 2)
This error occurs when the next data is ready before contents of UARTi receive buffer is read.
Select function
•CLK polarity selection
Whether transmit data is output/input at the rising edge or falling edge of the transfer clock can be
selected
•LSB first/MSB first selection
Whether transmission/reception begins with bit 0 or bit 7 can be selected
•Continuous receive mode selection
Reception is enabled simultaneously by a read from the receive buffer register
•Transfer clock output from multiple pins selection (UART1)
UART1 transfer clock can be chosen by software to be output from one of the two pins set
•Switching serial data logic (UART2)
Whether to reverse data in writing to the transmission buffer register or reading the reception buffer
register can be selected.
•Switching serial data logic (UART2)
This function is reversing TxD port output and RxD port input. All I/O data level is reversed.
