Electrical characteristics
M30240 Group
Rev.1.00 Sep 24, 2003 Page 124 of 360
1.4 Specifications
1.4.1 Electrical characteristics
Note 1: When writing to EPROM, CNVss rated value is -0.3 to 13 volts
Table 1.37: Absolute maximum ratings only, not operating conditions
Symbol Parameter Condition Rated Value Unit
V
cc
Supply voltage Vcc=AVcc -0.3 to 6.5 V
AV
cc
Analog supply voltage VCC=AVCC -0.3 to 6.5 V
V
I
Input voltage
Port0, Port1, Port2, Port3,
Port6,
Port7, Port8, Port10,
R
ESET, VREF, XIN
-0.3 to Vcc+0.3 V
V
I
Input voltage CNVss -0.3 to 6.5 (Note 1) V
V
O
Output voltage
Port0, Port1, Port2, Port3,
Port6,
Port7, Port8 (except P85),
Port10, R
ESET, VREF,
X
OUT
-0.3 to Vcc+0.3 V
P
d
Power dissipation Ta=25°C760 mW
T
opr
Operating ambient temperature 0 to 70 °C
T
stg
Storage temperature -65 to 150 °C
